High speed alcohol swabs 2ply packaging machine works steadily and continuously, it is suitable for the production various kinds of four side sealing products of all types wet wipes,wet tissue, alcohol swabs,alcohol prep pad,alcohol pad and so on.

Production process:
Nonwoven cloth onto the machine→folding→cutting→adding liquid→into the bags→making the bags→sealing the bags→cutting→final products

Features：
1.High-sensitivity photoelectric eye color mark tracking, digitally input the sealing and cutting position, making the sealing and cutting position more accurate.
2.Independent PID control of temperature, better adapt to various packaging materials.
3.Positioning stop function, no sticking of knife, no waste of film.
4.The transmission system is simple, the work is more reliable, and the maintenance is more convenient.

Main technical data:
Name:High Speed Alcohol Swabs 2Ply Packaging Machine
Model:PPD-6L540
Alcohol pad unfolded size:60mm x 30mm
Alcohol pad folded size:30mm x 30mm
Packing size:50mm x 50mm
Nonwoven width:60cm
Process capability: 480-540 package/min.
Packing materials: 73-110g/square meterpaper and aluminum compound materials
Packing materials specification:Φ≤350 mm,width 600 mm,papar core inner diameter:76.2mm
Suitable wipes materials: roll shape,40-70g/square meter:spunlace nonwoven materials
Non-woven materials specifications: OD ≤ 600mm ,Width 60 mm
Paper core inner diamater: 76.2mm (=3")
Total power: 220v ,50hz ,2.6 kw
Weight: 500 kg
Machine packing size : L2260×W1360×H1520mm
